Endurance magnetic base drill up to 1-1/4 in [32 mm]
Small, extremely lightweight 1-speed Endurance magnetic core drill with basic functionality for core drilling on the construction site.
Details
- For tough use, thanks to high-quality workmanship and internal motor cable routing.
- Uncompromising service life through extra-durable gearbox design with up to 400 hours of operation time.
- Lightweight with FEIN high-performance motor and high torque for all core drilling work.
- Excellent price / performance ratio.
- Easy to read convenient magnetic holding force display.
- Internal cooling.
- High magnetic holding force.
- Hand feed wheel can be mounted on either side.
- Good accessibility in cramped operating situations.
- Personal safety switches.
Technical data
Power consumption |
1200 W |
Power output |
770 W |
Full load speed |
450 rpm |
No load speed |
700 rpm |
Carbide cutter max. dia. |
1-1/4 [32] in[mm] |
HSS cutter max. dia. |
1-1/4 [32] in[mm] |
Cutter max. drilling depth |
2 [50] in[mm] |
Cutter holder |
3/4" Weldon |
Stroke |
3-9/16 [90] in[mm] |
Magnetic holding force |
2248 [10,000] lbs[N] |
Magnetic base dimensions |
6-7/8 [175] x 3-1/8 [80] in[mm] |
Cable with plug |
9.8 [3] ft[m] |
Weight |
23.81 [10.80] lbs[kg] |
Price includes
- 1 coolant tank
- 1 safety strap
- 1 chip hook
- 1 centering pin dia. 1/4 x 3-1/8 [6.35 x 80] in[mm]
- 1 centering pin dia. 1/4 x 4 [6.35 x 100] in[mm]
- 1 centering pin dia. 3/16 x 4 [4.75 x 100] in[mm]
- 1 chip guard
- 1 allen key 5 mm
- 1 case
